Technical Specification FM250 Flow Monitor
Overview
| The WaterCompass FM250 offers effortless installation on any meter employing a magnetic-coupled register or a pulse output meter. This flow monitor seamlessly integrates without disrupting meter functionality, enabling installation even while water is flowing—eliminating the need for water shut-off or pipe cutting. Its battery-powered operation eliminates the necessity for wiring, electrician assistance, or trench digging, facilitating a straightforward, non-invasive setup process. |
Technical Information
Size |
L: 4” |
W: 4” |
H: 2.5” |
|
Weight |
1.675 lbs. |
|||
Antenna connection |
Female SMA Connector |
|||
Cable length |
Sensor - 12 ft. |
Pulse Dongle – 1 ft. |
||
Battery Life |
5 years |
|||
Data Inputs |
Magnetic Sensor or Dry Contact Pulse |
|||
Data Collection |
Data uploaded daily |
|||
FCC ID |
2ANPǪ00NRF9160 & X8WBM833F |
|||
Operating Temp Range |
50°C (32° – 122°F) |
|||
Accuracy in Water Meter Flow Range |
+\- 5% of meter reading |
|||
